Photodon 2-Way and 4-Way Privacy Filters
How To Order a Privacy Filter
Photodon can custom cut a privacy filter for you up to 55" diagonal.
Method 1: NO Measurement NeededQuick Find Your Device
First check our Quick Find to see if we have your device in our database. If your device is found, you will have the option to order a privacy filter from that product page.
Method 2: Measurement RequiredCustom Cut Filters
If you do not find your device in our Quick Find, you can order a Custom Cut filter using our custom cut form page. Custom cut privacy filters for any device up to 55" diagonal for 2 way, and 27" diagonal for 4 way.
Or order a standard monitor filter by screen ratio.
Unsure about which material is best for you? Sample Filter Packs are an easy, low-risk way to try our products before you buy the actual size!
A must have for privacy on your computer
We specialize in curved monitors and installations
Privacy filters can help provide privacy for you or your customer's information. The mini-louvers embedded in privacy filters reduce screen viewing at about 30 degrees and turn the screen nearly black at angles greater than 45 degrees.
HIPAA and other privacy policies require businesses to protect personal information from the public or other non-essential personnel. Ensuring customer trust requires businesses to keep client information private. continue reading...
View our Privacy Filter Brochure to see why you should consider a Photodon filter for your privacy filter purchase.
Photodon Privacy Filters
Three types of Touché™ brand Privacy Filters
|Full silicone back adhesion|
|2 Way Privacy||4 Way|
|Material cut size mm||1309 x 669||901 x 723||466 x 466|
|Material cut size inches||51 1/2 x 26 15/16||34 13/16 x 28 15/16||18 5/16 x 18 5/16|
*Privacy filter mini louvers are normally situated vertically with privacy feature from left to right. Rotating the sheet 90 degrees to portrait mode with privacy feature from top to bottom, will reduce the maximum width achievable without the introduction of a seam.
P2L tab attachment is easier to attach and can be removed and reapplied as needed. The adhesion tabs can be cleaned if they become dirty from use.
P2S & P4S filters have full Silicone adhesion over the entire back surface and is more difficult to install than the P2L material but gives a slightly better look and function once installed. This type of adhesion is removable but not intended to be removed and replaced on a regular basis as the P2L material is able to.
Normal orientation for the 2-way privacy filter material is privacy left and right, however it can be rotated 90° to provide privacy top to bottom. 4-way privacy filter provides privacy from 4 directions typical application is on tablets.
HIPAA Law and other privacy policies require businesses to protect personal information from the public or other non-essential personnel. Ensuring customer trust requires businesses to keep client information private. Privacy filters can help provide privacy from persons not directly in front of the screen.
The mini-louvers embedded in privacy filters reduce screen image visibility starting at angles of about 30° and turns the screen nearly black at angles greater than 45°. When viewing the screen from straight on, the image is clear. The filter slightly dims the light that the computer screen emits, this can be soothing to the eyes. Some consumers may choose to increase the screen brightness. Increasing screen brightness will slightly reduce the privacy effect. Decreasing screen brightness will tend to increase screen privacy slightly. These filters have an anti-glare (matte) side and a glossy side. Use the matte side on the side facing out to reduce screen reflections, the glossy side can also face out if desired with no effect on the privacy feature.
- Provides screen privacy from the sides
- Touchscreen Compatible
- Anti-glare hides fingerprints and reduces glare
- Protects the screen from impact and scratch damage
- Reduces screen brightness. Some people find the reduced brightness easier on the eyes
- Reduces Bluelight (50% 310-375nm)
- Installation and care kit included
- Top-quality materials
- 18-month limited warranty
- Reduces screen brightness; may require you to increase screen brightness
- Does not reduce screen image from persons directly behind the user
Excess blue light that can have a negative effective on your health and your eyes. These filters also reduce the high energy Blue Light by approximately 50% (between 310 and 375nm).
They also block Ultra-Violet transmittance to less than 1% (between 250 and 325nm).
Protecting customer information is a primary concern for many industries.
Point of Sales
Videos and Blog Articles
Computer Privacy Screens For Curved Monitors
How Are Privacy Filters Made And How Do They Function?
Privacy Filters Facilitate Hospital HIPAA Compliance
Our Standard Sizes Monitor Privacy Filters
Photodon privacy filters fit within the bezel and lay flat on the screen surface. To order your privacy filter from the Standard Size chart below, first measure your monitor screen area within the bezel border (height and width).
Regarding Measuring: If unsure about the measurement process, watch our short video on how to measure. Having the correct dimensions is very important when ordering a custom screen protector. We do not use the diagonal dimension to make a custom cut screen protector, but it is helpful in identifying the device.
Then select from the chart the privacy filter that is closest but not larger than what you have measured your screen to be. Ordering a filter that is larger will result in the filter not being able to lay flat to the screen surface and you will not like that effect. If you feel the filters offered on the Standard Sizes chart does not fit your device properly, you can easily order a custom cut filter by visiting our custom cut page.
|Product SKU||Monitor Size||Filter Dimensions (in)
Width x Height
|Filter Dimensions (mm)
Width x Height
|U19S-P2L||19" Standard (5:4)||14 13/16 x 11 7/8||375.6 x 302.4||Purchase Filter|
|U19W1610-P2L||19" Widescreen (16:10)||16 1/16 x 10 1/16||408.4 x 256||Purchase Filter|
|U195W-P2L||19.5" Widescreen (16:9)||17 x 10 1/16||431.8 x 256||Purchase Filter|
|U20W-P2L||20" Widescreen (16:9)||17 7/16 x 9 13/16||442.8 x 249.6||Purchase Filter|
|U215W-P2L||21.5" Widescreen (16:9)||18 3/4 x 10 9/16||476.2 x 269||Purchase Filter|
|U22W1610-P2L||22" Widescreen (16:10)||18 11/16 x 11 11/16||475.2 x 297.4||Purchase Filter|
|U23W-P2L||23" Widescreen (16:9)||20 1/16 x 11 5/16||510 x 287.4||Purchase Filter|
|U236W-P2L||23.6" Widescreen (16:9)||20 9/16 x 11 9/16||523 x 294.4||Purchase Filter|
|U238W-P2L||23.8" Widescreen (16:9)||20 3/4 x 11 11/16||527 x 297.4||Purchase Filter|
|U24W1610-P2L||24" Widescreen (16:10)||20 7/16 x 12 3/4||519 x 323.8||Purchase Filter|
|U24W-P2L||24" Widescreen (16:9)||20 15/16 x 11 13/16||532 x 300.4||Purchase Filter|
|U27W-P2L||27" Widescreen (16:9)||23 9/16 x 13 1/4||599.2 x 337.2||Purchase Filter|
|U27W1610-P2L||27" Widescreen (16:10)||22 15/16 x 14 5/16||582.6 x 363.5||Purchase Filter|
|U28W1610-P2L||28" Widescreen (16:10)||23 3/8 x 14 5/8||593.7 x 371.5||Purchase Filter|
|U28W-P2L||28" Widescreen (16:9)||24 7/16 x 13 1/2||620.7 x 343||Purchase Filter|
|U29W219-P2L||29" Widescreen (21:9)||26 1/2 x 11 1/4||673.1 x 285.8||Purchase Filter|
|U30W-P2L||30" Widescreen (16:10)||25 3/16 x 15 3/4||639.8 x 400||Purchase Filter|
|U315W-P2L||31.5" Widescreen (16:9)||27 7/16 x 15 7/16||696.9 x 392.1||Purchase Filter|
|U32W-P2L||32" Widescreen (16:9)||27 8/9 x 15 2/3||708.4 x 397.9||Purchase Filter|
|U34W219-P2L||34" Widescreen (21:9)||31 3/8 x 13 3/16||796.9 x 335||Purchase Filter|
|U38W219-P2L||38" Widescreen (21:9)||35 3/16 x 14 13/16||893.8 x 376.2||Purchase Filter|
|U43W-P2L||43" Widescreen (16:9)||37 1/16 x 21||941.4 x 533.4||Purchase Filter|
If none of the filter sizes in the chart match your monitor, use our Custom Cut Privacy Filter page to order the size for your screen.
Order a Custom Cut Privacy Filter
